High Efficiency 15° Viewing Angle PMMA TIR LED Lens for COB Spot Light

Name: High Efficiency 15 Viewing Angle PMMA TIR LED Lens for COB Spot Light
Brand: Wisertop
Price: 1 USD

Brand Name : Wisertop

Model Number : WT-45@22-15COBL9-Y1

Certification : Rohs

Place of Origin : China

MOQ : 1pc

Price : Shenzhen Wisertop Technology Co.,Ltd

Supply Ability : 100,000 day

Delivery Time : 1-2 weeks

Packaging Details : Master carton

Material : PMMA

Lens type : TIR Lens

Efficiency : 93%

Certificates : Rohs

Working temperature : -40°C~+70°C

Light source : Brand COB leds as Cree Osram Lumileds Bridgelux...

Contact Now

High Lighting Efficiency Match Osram LED Lenses Viewing Angle 15 Degree

Product Overview

Viewing angle 15° COB Lens PMMA material for Spot light with high lighting efficiency, compatible with Osram COB Diameter 45mm.

Applications

Spot light, Down light, Tracking light, Recessed lamp, Ceiling light

Lens Material

PMMA all available

Lens Features

High K value
Accurate viewing angle, illuminated object is clear and recognizable
High light transmittance
Maintain high color resistance
The main light halo fades naturally
Low glare and good shape light area

Compatible COB Light Sources

Cree, Lumileds, Bridgelux, Citizen, and more

Specifications

Part no	Light-emitting surface	FWHM	Size (mm)	Typ.eff	Material
WT-45@22-15COBL9-Y1	¢6mm COB	15°	φ44.8×22.5	93%	PMMA
WT-45@22-24COBL9-Y1	¢9mm COB	24°		93%	PMMA
WT-45@22-36COBL9-Y1	¢9mm COB	36°		93%	PMMA
WT-45@22-50COBL9-Y1	¢9mm COB	50°		93%	PMMA

High Efficiency 15° Viewing Angle PMMA TIR LED Lens for COB Spot Light

Frequently Asked Questions

Can I have a sample order?

Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable.

When can I get the quotation?

We usually provide an offer within 12 hours after receiving your inquiry. For urgent requests, please call or email us.

What is the lead time?

Samples require about 3-5 days for preparation, while mass production typically takes 1-2 weeks.

What are your main products?

Our main products are indoor lenses.
